FEIN - 2-Gang Akku-Schlagbohrschrauber ASB 18 Q AS Set 5 Ah

Application
Mit bürstenlosem Motor und QuickIN Schnittstelle. Perfekt geeignet für Bohren bis 13 mm in Metall, Stein und Mauerwerk.

Execution

Vollmetall-Getriebe mit 2 Gängen und zuschaltbarem Schlagwerk für optimales Bohren in Metall, Stein und Mauerwerk.
Die größte Anwendungsvielfalt mit dem FEIN QuickIN-System. Schnelleres Arbeiten in Metall und Holz mit nur einer Maschine
QuickIN Vollmetall-Bohrfutter (120 Nm) mit hartmetallbestückten Spannbacken und hohen Spannkräften.
Bürstenloser FEIN PowerDrive Motor mit 30 % höherem Wirkungsgrad und langer Lebensdauer.
Mechanische Drehmomenteinstellung.
Kompakte Bauweise.
Ergonomische und flexible Handhabung durch seitlich angebrachte Bit- und Gürtelhalter.
Kompatibel mit Bosch Professional 18 V Akkus seit 2008 und AMPShare Akkus.
Ausstattung: abnehmbares Bohrfutter, zuschaltbares Schlagwerk, QuickIN Zubehör-Schnittstelle

Advantage

Die AMPShare Schnittstelle ermöglicht fast 50 % mehr Verschraubungen (ca. 1 300 Verschraubungen Ø 5 x 40 mm in Holz) pro Akku-Ladung bei bestehender FEIN Qualität. (ProCORE 4 Ah).
Kompatibel mit allen 18 V AMPShare ProCORE-Akkus und Ladegeräten für noch mehr Power und Flexibilität. Passend auch für 18 V Bosch Professional Akku-Geräte.
Maximaler Arbeitsfortschritt mit AMPShare 18 V ProCORE Akkus: COOLPACK 2.0-Technologie sorgt für eine um 135 % längere Akkulebensdauer. Modernste Zelltechnologie und intelligentes Akku-Management sorgen für 87 % mehr Leistung als bei konventionellen Akkus. „Electronic Cell Protection" ECP schützt den Akku vor Überlastung, Überhitzung und Tiefentladung.

Delivery
Akku-Schlagbohrschrauber
QuickIN Bohrfutter (120 Nm)
Gürtel-Clip
Bitgarage
Kunststoff-Werkzeugkoffer (L-BOXX 136)
2 Akkus LiIon GBA 18 V 5.0 Ah AS
Schnellladegerät GAL 1880 CV AS

Brand: FEIN
Max. torque: 60 Nm
Max. impact rate: 32000 rpm
Torque levels: 22+1
Tool holding device: QuickIN
Battery included in delivery: Yes
Battery voltage: 18 V
Rechargeable battery/battery capacity: 5 Ah
Max. idle speed: 2000 rpm
Motor design: Brushless motor
Max. drilling diameter in steel: 13 mm
Max. thread-cutting performance: M10
Weight: 1,19 kg
Min./max. drill chuck span width: 1.5-13 mm
Screw diameter x screw length: 8 x 300 mm
Max. torque hard/soft: 60 / 38 Nm
Sound-pressure level: 92,9 dB
Noise level: 100,9 dB
Max. drilling diameter in stone in 2nd gear: 13 mm
Max. drilling diameter in wood: 50 mm
Idle speed 1st gear min./max.: 0-450 U/min(rpm)
Idle speed 2nd gear min./max.: 0-2000 U/min(rpm)
Min./max. idle impact rate 1st gear: 0-7360 U/min(rpm)
Min./max. idle impact rate 2nd gear: 0-32000 U/min(rpm)
Type: ASB 18 Q AS Set 5 Ah
