Multi-purpose cylinder 5 t single-acting max. 700 bar type RC 55

Multi-purpose cylinder 5 t single-acting max. 700 bar type RC 55

Multi-purpose cylinder 5 t single-acting max. 700 bar type RC 55
Item no: 1080600 103

Online price:

Available in 8-10 working days.

Execution
  • Single-acting
  • Max. operating pressure 700 bar
  • Pistons made from hard-chrome-plated, quality steel
  • With replaceable, grooved pressure piece, powerful retraction spring, wiper ring
  • Male thread on the cylinder head, piston rod internal thread and mounting thread on the cylinder bottom
  • Coupling sleeve with dust cap


Brand: ENERPAC
Model: RC 55
Max. compressive force: 45 kN
Lift height: 127 mm
Oil capacity: 83 cm³
Construction height, retracted: 215 mm
Weight: 1,9 kg
Effective piston area: 6,5 cm²
Max. operating pressure: 700 bar

Manufacturer part no.: RC 55
