ATORN inside micrometer, analogue, 175-200 mm measuring range, in case

ATORN inside micrometer, analogue, 175-200 mm measuring range, in case

ATORN inside micrometer, analogue, 175-200 mm measuring range, in case
Item no: 1031899 117

Online price:

Available in 13-15 working days.

Application
For measuring through-bores and short centring shoulders.

Execution
  • Scale with anti-glare, brushed chromium plated finish
  • Measuring faces made of hardened steel
  • Friction coupling for consistent, repeatable measuring force

Delivery
In a case

Notes
For measuring depth extensions, see 1031899122-125.

Brand: ATORN
Min./max. length measuring range: 175-200 mm
Measuring depth: 132 mm
Error limit: 7 µm
Vernier scale: 0.005 mm
Measuring spindle increments: 0,5 mm
Calibration Group: I
DIN: 863

ATORN-No.: 31050127

EAN no.: 4050293642278

Product Datasheet
