ApplicationFor measuring e.g. shaft diameters, external dimensions on workpieces etc.
Execution- High-contrast digital display
- Fully hardened and ground stainless steel measuring spindle
- Carbide-reinforced measuring spindle and anvil
- QUICK DRIVE quick adjustment
- Non-rotating spindle
- Ratchet tool at the front
- Functions: RESET (sets the display to zero), ABS (display can be set to zero without losing the reference to the ORIGIN), mm/inch, ORIGIN (measurement presetting), LOCK function (key lock), TOL (input of tolerances and warning limits), HOLD (measured value storage), DATA, bi-directional data interface (external querying and input of characteristic values as well as adjustment of individual function blocks via MarCom software)
AdvantageThermally insulated painted steel frame
Delivery1x 3 V battery (type CR 2032)
1x operating instructions
1x case
1x setting gauge (from measuring range 25-50 mm)
Notes- For setting gauges, see art. no. 1031579.
- For i-Stick wireless receiver for 1031560 501-504, see art. no. 1035200 410
- For connection cables for 1031560 401-404, see art. no. 1035200 415-416.
- For replacement batteries, see art. no. 1039900 102.
Software: MarCom Professional free download: www.mahr.com/marcom (only for Mahr data cables and wireless systems with USB and RS232 interface).
