Precision pocket vernier callipers 0-300 mm TC meas. surf. f. ext. meas.

Precision pocket vernier callipers 0-300 mm TC meas. surf. f. ext. meas.

Precision pocket vernier callipers 0-300 mm TC meas. surf. f. ext. meas.
Item no: 1031014 503

Online price:

Available in 11-13 working days.

Application
For measuring external, internal, step and depth dimensions.

Execution
  • Vernier scale and scale with brushed chrome-plated finish for glare-free reading
  • Locking screw at the top
  • Carbide-tipped external measuring surfaces
  • Slide and rail hardened, rust-free

Advantage
  • Elevated guideways
  • Easy reading via 14° inclined vernier scale

Delivery
1x box


Brand: MITUTOYO
Min./max. length measuring range: 0-300 mm
Vernier scale: 0.05 mm
Depth gauge rod: Flat
Length of jaw: 64 mm
Length of cross tips: 27,5 mm
Error limit: 0,1 mm
Other standard: Company standard
Type of locating: With locking screw
Calibration Group: A

Manufacturer part no.: 530-322

EAN no.: 4946368110424

Product Datasheet
