ATORN mini cutting insert ATR 7.0mm R0.2 L30 HC5615

ATORN mini cutting insert ATR 7.0mm R0.2 L30 HC5615

ATORN mini cutting insert ATR 7.0mm R0.2 L30 HC5615
Item no: 1018316 203

Online price:

Available in 4-6 working days.

Application
For longitudinal internal boring in steel, stainless steel, special alloys material groups, hard machining to 65HRC at high cutting speeds and mid-range cutting conditions.

Execution
Solid carbide cutting insert with 96° attack angle with internal cooling

Advantage
  • Very hard cemented carbide grade ensures low wear
  • Stable geometry optimised for longitudinal internal boring machining
  • Innovative coating technology for universal use with very high service life requirements


Brand: ATORN
Shank diameter (D): 7 mm
ISO name: AT
Length (L): 62 mm
Clearance length (L1): 30 mm
Radius (R): 0,2 mm
Programming size (F): 3,3 mm
Min. bore diameter (D min.): 7,1 mm
Machining direction: Right
Carbide type: HC5615
Material to be processed: Steel | Stainless steel | Special alloy | Hardened material

ATORN-No.: 11946546

EAN no.: 4050293371017

Product Datasheet
