Digimatic IP65 micrometer 25-50 mm

Digimatic IP65 micrometer 25-50 mm

1001355986 Digimatic IP65 micrometer 25-50 mm
Item no: 1001355 986

Online price:

Available in 11-13 working days.

Application
For measuring e.g. shaft diameters, external dimensions on workpieces etc.

Execution
  • Carbide-tipped and micro-lapped measuring surfaces
  • Semi-gloss chrome-plated thimble and sleeve, dia. 18 mm
  • A ratchet thimble ensures reproducible measurement
  • Functions: ORIGIN (up to 100 mm), ABS/INC (INC ZERO), automatic switch-off after 20 minutes of inactivity, low voltage alarm, function lock, HOLD

Advantage
  • Oil-resistant material for all plastic parts
  • Exceptional battery life of 2.4 years
  • Excellent resistance to water and dust

Delivery
1x box
1x adjustment wrench
1x battery
1x setting standard (from 25 mm)
1x factory test certificate (up to 50 mm measuring range)


Brand: MITUTOYO
Min./max. length measuring range: 25-50 mm
Digit increment: 0,001 mm
Measuring spindle increments: 0,5 mm
Measuring surface diameter: 6,35 mm
Data transmission type: No
Error limit: 0,001 mm
IP protection class: IP 65
Other standard: Company standard
Spindle clamping: Yes
Digit height: 7,5 mm
Min./max. measurement force: 5-10 N
Number of setting dimensions: 1 PCS
Calibration Group: D | E

Manufacturer part no.: 293-245-30

Product Datasheet
