Filter regulator FU 812-10 flow rate 2,500 l/min filter Cellpor 5 µm fine

Filter regulator FU 812-10 flow rate 2,500 l/min filter Cellpor 5 µm fine

Filter regulator FU 812-10 flow rate 2,500 l/min filter Cellpor 5 µm fine
Item no: 1092422 202

Online price:

Available in 5-7 working days.

Application
For cleaning and adjusting the working air.

Execution
  • NBR seals
  • Housing made from die-cast zinc
  • Container made from polycarbonate
  • With pressure gauge
  • Manual condensate draining

Advantage
Filter pressure regulators combine the functions of a filter and a pressure regulator in one space-saving device

Notes
If direct mounting on distributor boxes, compressors and machines is not possible, the device can be attached using the appropriate bracket mount.

Brand: RIEGLER
Connection thread: G 3/8 inch
Filtration grade: 5 µm
Min./max. pressure control range: 0.5-10 bar
Container volume, filter: 28 cm³
Width x height: 54 x 226 mm
Condensate drain: Semi-automatic
Cylinder diameter: 52 mm
Flow capacity: 2500 l/min
Length: 226 mm
Length 2: 96 mm
Manometer display: 0-16 bar
Material of bins: Polycarbonate
Material of connection thread: Die-cast zinc
Material of filter: Cellpor (PE)
Material of gasket: Nitrile butadiene rubber (NBR)
Material of housing: Polyamide 66 GF60
Material of membrane: NBR (Nitrile Butadiene Rubber)
Max. inlet pressure: 16
Max. temperature conditions: 50 °C
Min. inlet pressure: 1.5
Min. temperature conditions: -10 °C
Type: FU 812-10

Manufacturer part no.: FU 812-10

EAN no.: 4047322595353

Product Datasheet
