Slanting rack basic bay, 4 levels, zinc-plated 2000x1300x1228mm

Slanting rack basic bay, 4 levels, zinc-plated 2000x1300x1228mm

Slanting rack basic bay, 4 levels, zinc-plated 2000x1300x1228mm
Item no: 1085490 102

Online price:

Availability on demand

Execution
  • Easy and quick plugin assembly with flat-pack S3 slot-in frames
  • FIFO principle (first in/first out): The products stored first are used first (particularly important for goods with expiry dates)
  • The uppermost level is fully available for loading since there are no crossbraces
  • The shelves have an 18° incline so that goods stored on them virtually move themselves forwards for removal
  • The shelves have no protruding edges in the direction of the incline
  • Low front stop side for easy removal of boxes and crates
  • Shelves adjustable in increments of 25 mm
  • Lateral guide available on request
  • Basic shelf planning dimensions: Nominal length + 56 mm, frame depth 1228 mm (overall)

Notes
Shelves with a height/depth ratio greater than or equal to 5: 1 must be secured against tipping (anchored to the wall or floor). The loads indicated per shelf and per bay apply to evenly distributed loads. Shelf load specifications apply to rack rows with 3 or more bays. Cover shelf max. 200 kg

Brand: META
Load-carrying capacity per shelf: 200 kg
Number of shelves: 4 PCS
Nominal depth: 1228 mm
Load-carrying capacity per field: 1200 kg
Nominal length: 1300 mm
Height: 2000 mm
Depth: 1228 mm
With compartment divider: No
Grid dimension: 25 mm
Type of assembly: To insert
Material: Steel
Surface: Zinc plated
Length: 1356 mm

Manufacturer part no.: 20091078

EAN no.: 4026212238198

Product Datasheet
