System panel for base frame

System panel for base frame

System panel for base frame
Item no: 1082075 922

Online price:

Availability on demand

Application
For inserting in base frame to accommodate RasterPlan support elements and tool holders in 10 x 10 mm hole grid.

Execution
  • With rectangular hole grid 10 x 10 mm, 38 mm spacing
  • Internally bolted to the base frame


Brand: ANKE
Height: 638 mm
Width: 523 mm
Punched-hole: 10 x 10 mm
Material: Sheet steel
Colour: Light grey RAL 7035

Manufacturer part no.: 903.710

EAN no.: 4014641063894

Product Datasheet
