Precision scale magnifier lens dia. 23 mm achromatic lens magnification 10x

Precision scale magnifier lens dia. 23 mm achromatic lens magnification 10x

1039242102 Precision scale magnifier lens dia. 23 mm achromatic lens magnification 10x
Item no: 1039242 102

Online price:

Still in stock: 7

Application
For measuring on flat surfaces, e.g. small bore diameters, paint damage etc.

Execution
  • Achromatic glass lens, tempered
  • Distortion-free and razor-sharp image
  • Focus adjustment using non-slip focusing ring
  • Measuring range 10 mm

Delivery
With scale type A reticule plate (art. no. 1039242 201)


Brand: ESCHENBACH
Magnification: 10-times
Lens diameter: 23 mm
Lens design: Achromatic
Max. length measuring range: 20 mm
Scale value: 0,1 mm

Manufacturer part no.: 115410

EAN no.: 4026158054333

Product Datasheet
