Layer thickness gauge QNix® 4200 P for steel and iron

Layer thickness gauge QNix® 4200 P for steel and iron

Layer thickness gauge QNix® 4200 P for steel and iron
Item no: 1039152 201

Online price:

Available in 8-10 working days.

Application
For measurements on steel and iron. Specially designed for automotive and painting applications.

Execution
  • High degree of measuring accuracy over the entire measuring range
  • Only one function key
  • Proven Hall sensor technology
  • One-handed operation for all measuring tasks
  • No calibration necessary on uncoated base material
  • Integrated sensor without cables or connectors
  • Measuring accuracy: +/- (2 µm + 3 %*) (*of the measured value)
  • Smallest curvature radius: 5 mm convex/25 mm concave
  • Automatic switch on/off function
  • Metric or inch display can be selected
    • Acoustic signal at start of measurement

    • LCD for measurement value, battery status, measuring unit, operating mode and serial number

Delivery
- Layer-thickness measuring instrument
- 2 x 1.5 V LR 6 AA batteries
- Device case with zero references
- Test certificate
- Operating instructions

Notes
For replacement batteries, see art. no. 1039900 303.
Other QNix® layer-thickness measuring instruments with various accessories available on request. Please get in touch!

Brand: QNIX
Probe design: F
Type: 4200 P
Test probe: Integrated
Min./max. layer thickness display range: 0-3000 µm
Min./max. layer thickness of measuring range: 0-3000 µm
Data transmission type: No
Max. layer thickness of measuring range: 3000 µm
Min. layer thickness of measuring range: 0 µm
Battery designation: 1.5 V Mignon AA
Display: Digital
Gross weight: 100 g
Height: 27 mm
Internal memory: No
Length: 100 mm
Max. layer thickness display range: 3000 µm
Max. operating temperature: 50 °C
Min. layer thickness display range: 0 µm
Min. operating temperature: 0 °C
Min./max. operating temperature: 0 to 50 °C
Number of rechargeable batteries/batteries: 2 PCS
Width: 60 mm

Manufacturer part no.: 785064

Product Datasheet
