Depth measuring bridge individual clamping dia. 8 mm h6 prismatic meas. surface

Depth measuring bridge individual clamping dia. 8 mm h6 prismatic meas. surface

Depth measuring bridge individual clamping dia. 8 mm h6 prismatic meas. surface
Item no: 1033236 201

Online price:

Available in 6-8 working days.

Application
For measuring the depth of keyways in cylindrical shafts of 10 to 100 mm dia., roundness deviations etc.

Execution
  • With prismatically arranged measuring surfaces
  • Opening angle of the measuring surfaces 120°
  • Hardened steel, brushed chromium-plated measuring bridge
  • Measuring surface finely lapped, 16 mm wide
  • Mount with clamping equipment for dia. 8 mm H7


Brand: TESA TECHNOLOGY
Length: 66 mm
Width: 16 mm
DIN: 874
Locating bore hole diameter: 8 mm

Manufacturer part no.: 01639047

EAN no.: 4024496081400

Product Datasheet
