Parallel individual gauge block, special steel DIN/ISO 3650 tol. cl. 1 1.0005 mm

Parallel individual gauge block, special steel DIN/ISO 3650 tol. cl. 1 1.0005 mm

Parallel individual gauge block, special steel DIN/ISO 3650 tol. cl. 1 1.0005 mm
Item no: 1032027 199

Online price:

Available in 8-10 working days.

Application
To supplement and replace damaged or worn gauge blocks.

Execution
Cross-section dimensions:

Nominal dimension range under 0.3 mm = 20 x 9 mm, up to 10.1 mm = 30 x 9 mm, above 10.1 mm = 35 x 9 mm.

Delivery
Nominal dimension of 125 mm and above supplied in a storage box

Notes
Metric individual gauge blocks in calibration/tolerance class DIN EN ISO 3650 K and DKD test reports are deliverable on request.
Additional carbide and ceramic parallel individual gauge blocks are deliverable on request.

Brand: LIZZARD
Calibration Group: AF
Nominal dimension: 1,0005 mm
Tolerance class: 1
Material: Gauge steel
ISO: 3650

EAN no.: 4024496074198
