Brand: ATORN
Shape of indexable insert ISO: D
Clearance angle of indexable insert ISO: N
Tolerance class of indexable insert ISO: M
Indexable insert type ISO: G
Size of indexable insert ISO: 11
Thickness of indexable insert ISO: 04
Corner radius of indexable insert ISO: 04
Coating: PVC
Carbide type area ISO: P
Machining conditions for indexable insert: Good
Carbide type ISO: P25
Carbide type: ACP25T
ISO-Code Rotating: DNMG 110404
Material to be processed: Cast metal | Steel | Stainless steel
min./max. ap: 0.25-2.5 mm
f min./max.: 0.07-0.25 mm/U
Materials group: P (primary application) | M (secondary application) | K (secondary application)
f min.: 0,07 mm/r
max. f: 0,25 mm/r
max. ap: 2,5 mm
min. ap: 0,25 mm
Supply type: Smoothing
Chip breaker code: FP1
Min./max. Vc in steel: 100-240 m/min
Min./max. Vc in cast iron: 120-250 m/min
Min./max. Vc in stainless steel: 70-200 m/min
Number of pieces per packet: 10 PCS

ATORN-No.: 12370685

EAN no.: 4050293728408

Product Datasheet
