ATORN indexable insert TCMT 110304-MM2 ACM25T-1

ATORN indexable insert TCMT 110304-MM2 ACM25T-1

ATORN indexable insert TCMT 110304-MM2 ACM25T-1
Item no: 1018594 807

Online price:

Available in 6-8 working days.

Notes
Indexable insert TCMT 110304-MM2 ACM25T-1

Brand: ATORN
Shape of indexable insert ISO: T
Clearance angle of indexable insert ISO: C
Tolerance class of indexable insert ISO: M
Indexable insert type ISO: T
Size of indexable insert ISO: 11
Thickness of indexable insert ISO: 03
Corner radius of indexable insert ISO: 04
Carbide type area ISO: M
Machining conditions for indexable insert: Medium
Carbide type ISO: M25
Carbide type: ACM25T-1
ISO-Code Rotating: TCMT 110304
min./max. ap: 0.42-2.5 mm
f min./max.: 0.06-0.6 mm/U
f min.: 0,06 mm/r
max. f: 0,6 mm/r
max. ap: 2,5 mm
min. ap: 0,42 mm
Chip breaker code: MM2
Min./max. Vc in stainless steel: 110-240 m/min

ATORN-No.: 12350558

EAN no.: 4066107026776

Product Datasheet Datasheet cutting values
