Brand: ATORN
Shape of indexable insert ISO: D
Clearance angle of indexable insert ISO: N
Tolerance class of indexable insert ISO: M
Indexable insert type ISO: G
Size of indexable insert ISO: 15
Thickness of indexable insert ISO: 06
Corner radius of indexable insert ISO: 12
Coating: CVD
Carbide type area ISO: P
Machining conditions for indexable insert: Good
Carbide type ISO: P05
Carbide type: HC7605
ISO-Code Rotating: DNMG 150612
Material to be processed: Steel | Cast iron
min./max. ap: 0.5-6 mm
f min./max.: 0.1-0.6 mm/U
Materials group: K (secondary application) | P (primary application)
f min.: 0,1 mm/r
max. f: 0,6 mm/r
max. ap: 6 mm
min. ap: 0,5 mm
Supply type: Medium processing - Universal geometry with wide service range
Chip breaker code: MP1
Min./max. Vc in steel: 115-295 m/min
Min./max. Vc in cast iron: 135-395 m/min

ATORN-No.: 12350111

EAN no.: 4050293662344
