ATORN boring bar, positive, with internal cooling A20R SVQBR 11

ATORN boring bar, positive, with internal cooling A20R SVQBR 11

ATORN boring bar, positive, with internal cooling A20R SVQBR 11
Item no: 1018532 101

Online price:

Available in 4-6 working days.

Application
for longitudinal and copy turning with VB indexable insert, 35°

Execution
Precision-made boring bar, steel, with internal cooling, type V, attack angle 107.5°, tip angle 35°, clearance angle 5°

Advantage
  • very slim geometry, optimised for contour turning work
  • positive body geometry ensures low cutting forces


Brand: ATORN
ISO name: A20R SVQB R/L 11
Min. bore diameter (D min.): 25 mm
Shank diameter (d): 20 mm
Clearance length (l2): 20,5 mm
Length (l1): 200 mm
Clamping surface height (h): 18 mm
Suitable for indexable inserts (ISO): VB.. 1103..
Tool design: Right
DIN: 8024

ATORN-No.: 12232490

EAN no.: 4050293562323

Product Datasheet
