ATORN SDQC offset boring bar, steel, positive, right, A 0810 H SDQC R/L 07

ATORN SDQC offset boring bar, steel, positive, right, A 0810 H SDQC R/L 07

ATORN SDQC offset boring bar, steel, positive, right, A 0810 H SDQC R/L 07
Item no: 1018500 098

Online price:

Still in stock: 3

Application
For longitudinal and copy turning with DC 55° indexable insert.

Execution
Precision-manufactured boring bar, steel, with internal cooling, offset, shape D, 107.5° pitch angle, 55° tip angle, 7° clearance angle

Advantage
  • slim contour, optimised for copy turning work
  • positive body geometry ensures low cutting forces


Brand: ATORN
ISO name: A 0810 H SDQC R/L 07
Min. bore diameter (D min.): 12,5 mm
Tapered diameter (d1): 8 mm
Shank diameter (d): 10 mm
Clearance length (l2): 22 mm
Length (l1): 100 mm
Clamping surface height (h): 9 mm
Programming size (f): 7 mm
Suitable for indexable inserts (ISO): DC.. 0702..
Tool design: Right
DIN: 8024

ATORN-No.: 11111222

EAN no.: 4050293347333

Product Datasheet
