ATORN SC mini radius cutter TiAlSiN 1.2x0.96x50 mm clearance 1.16x4 mm

ATORN SC mini radius cutter TiAlSiN 1.2x0.96x50 mm clearance 1.16x4 mm

ATORN SC mini radius cutter TiAlSiN 1.2x0.96x50 mm clearance 1.16x4 mm
Item no: 1016790 155

Online price:

Available in 6-8 working days.

Application
Mini radius cutter with long neck for machining materials up to 65 HRC.

Execution
  • Cutting material, Ultra Micro fine grain
  • cutting edge finish
  • HA shaft in line with DIN 6535
  • Clearance
  • type H
  • With RockTec PRO coating
  • Radius tolerance = 0/-0.005 mm

Advantage
  • optimum chip removal and temperature resistance
  • Optimised geometry for machining hard materials
  • maximum service life thanks to RockTec PRO coating


Brand: ATORN
Cutting material: SC
Surface: RockTec PRO
Type: H
Number of cutting edges (Z): 2 PCS
Twist angle: 20°
Tool holding device: HA parallel shank
Construction length: Normal
Cutting edge diameter: 1,2 mm
Cutting edge length: 0,96 mm
Clearance length: 4 mm
Length: 50 mm
Clearance diameter: 1,16 mm
Shank diameter: 4 mm
fz hard 65 HRC: 0,013 mm

ATORN-No.: 11264369

EAN no.: 4050293655988

Product Datasheet Datasheet cutting values
