SC roughing cutter with IC HR TiAlN 25° normal HB shank T=4 dia. 20 mm

SC roughing cutter with IC HR TiAlN 25° normal HB shank T=4 dia. 20 mm

SC roughing cutter with IC HR TiAlN 25° normal HB shank T=4 dia. 20 mm
Item no: 1016569 106

Online price:

Still in stock: 3

Application
For materials up to HRC 45. Universal use up to 1300 N/mm²

Execution
  • Normal
  • With internal cooling in the flute
  • Fine cord profile
  • Centre cutting

Notes
Radial internal cooling results in a long service life and the chips are completely removed. Especially important when milling in solids and when milling out pockets.

Brand: LIZZARD
Material to be processed: Universal use
Cutting edge diameter: 20 mm
Cutting edge length: 38 mm
Length: 104 mm
Shank diameter: 20 mm
Number of cutting edges (Z): 4 PCS
Twist angle: 25°
Type: HR
Construction length: Normal
Cutting direction: Right-hand cutting
fz steel 1000: 0,08 mm
