S-S keyway cutter cyl. DIN 844 B ty. NF shrt 3 cutt. edg Z-cut HSS-E/TiAlN 10mm

S-S keyway cutter cyl. DIN 844 B ty. NF shrt 3 cutt. edg Z-cut HSS-E/TiAlN 10mm

S-S keyway cutter cyl. DIN 844 B ty. NF shrt 3 cutt. edg Z-cut HSS-E/TiAlN 10mm
Item no: 1016223 103

Online price:

Available in 6-8 working days.

Execution
  • Short
  • HSSE Co8
  • TiAlN coating
  • Right-cutting
  • Right-hand twist, approx. 30°
  • Centre cutting
  • Straight shank with driving surface in accordance with DIN 1835 B
  • With eccentric relief grinding


Brand: LIZZARD
Material to be processed: Universal use
Cutting edge diameter: 10 mm
Cutting edge length: 22 mm
Length: 72 mm
Shank diameter: 10 mm
Number of cutting edges (Z): 3 PCS
Tool holding device: HB parallel shank
Twist angle: 30° (right)
Center cutting: Yes
Type: NF
Construction length: Normal
Coolant supply: External
Design of cutting edges: Rough finishing
Cutting direction: Right-hand cutting
Tolerance of shank diameter: h6
Tolerance of cutting edge diameter: js14
