ATORN screw tap HSSE-PM ULTRA HL C 5156 50° G 1 2.5xD CNC UNI

ATORN screw tap HSSE-PM ULTRA HL C 5156 50° G 1 2.5xD CNC UNI

ATORN screw tap HSSE-PM ULTRA HL C 5156 50° G 1 2.5xD CNC UNI
Item no: 1014606 107

Online price:

Available in 6-8 working days.

Application
For producing pipe threads on CNC machines or conventional machines in blind holes in the steel, stainless steel, non-ferrous metals, cast and special alloy material groups up to a strength of 1200 N/mm².

Advantage
  • Universal use for maximum flexibility of application
  • Innovative cutter geometry ensures high process reliability even in difficult machining conditions


Brand: ATORN
Material to be processed: Universal use
Thread type: Pipe thread
Thread dimension: G 1 inch - 11
Thread type x nominal diameter in inches: G 1 in
Number of thread starts per inch: 11
Hole type: Blind hole ≤ 2.5xD
Lead angle shape: C
Length: 160 mm
Cutting material: HSSE-PM
Surface: ULTRA HL
Twist angle: 50° (right)
DIN: 5156
Shank diameter: 25 mm
Application type/machine type: CNC | Conventional
Core hole diameter: 30,75 mm
Type: UNI MAX 45HL Speed
Coolant supply: External
Shank square: 20 mm
Cutting speed (steel 1000) suitability (ISO P 1000 N/mm²): 1
Cutting speed (steel 1300) suitability (ISO P 1300 N/mm²): 1
Overall stainless steel suitability (ISO M): 1
fitness not iron total (ISO N): 2
fitness Titan/Nickel/Super total (ISO S): 1
Cutting speed (cast) suitability (ISO K): 1
Cutting speed (hard 55) suitability (ISO H 55HRC): 3
Cutting speed (hard 65) suitability (ISO H 65HRC): 3

ATORN-No.: 12280094

EAN no.: 4050293425284

Product Datasheet Datasheet cutting values
Versions
loading
Keywords:

[Text nicht gefunden]

  • ATORN screw tap HSSE TiN B 376 0° M36 4 mm ISO2 D 3xD CNC UNI
  •
    ATORN screw tap HSSE-PM ULTRA HL B 371 0° M10 1.5 ISO2 3xD CNC UNI
  •
    ATORN screw tap HSSE TiN B 376 0° M27 3 mm ISO2 D 3xD CNC UNI
  •
    ATORN solid carbide screw tap, IC C DIN 371 0° M8 1.25 mm ISO2 D/S 3xD CNC K
    209,84 €
  • ATORN thread mould HSSE Carbo DIN 371 M10 x 1.5 mm ISO 2 3xD
  •
    Machine tap G DIN 5156 15° shape C 2.5xD HSS-E 1/4 inch
  •
    Cable extension 180 cm for inspection cameras cat. no. 39317 201 and 39318 201
  •
    ATORN screw tap HSSE vap. B 376 0° M16 2 mm ISO2 D 3xD CNC UNI
  •
    ATORN SC radius cutter long diameter 2.0 x 4 x 14 x 75 mm T=2 RT52
  •
    Blind hole screw tap G DIN 5156 40° shape C 2.5xD HSS-E 3/8 inch
  •
    Replacement ceramic blade for KERAMICUT CR 2000 cat. no. 73350 101
  •
