Indexable drilling insert XPET 0703AP-SD:D8345 dia. range 21.5 to 26 mm

Indexable drilling insert XPET 0703AP-SD:D8345 dia. range 21.5 to 26 mm

Indexable drilling insert XPET 0703AP-SD:D8345 dia. range 21.5 to 26 mm
Item no: 1011181 204

Online price:

Availability on demand

Application
High-performance indexable inserts

Execution
  • AP geometry with universal design
  • AP-SD geometry in a positive design for centre indexable insert

Advantage
Suitable for various materials


Brand: DORMER PRAMET
ISO name: XPET 0703AP-SD
Surface: Coated
Cutting material: SC
Suitable for min./max. cutting diameter: 21.5-26 mm
Number of cutting edges: 4
Inner circle diameter (IC): 7,937 mm
Cutting edge length (L): 7,94 mm
Mounting bore diameter (D1): 2,90 mm
Thickness of indexable insert (S): 3,18 mm
Carbide type: D8345
Coating: PVD
Materials group: P (primary application) | M (primary application) | K (secondary application) | S (secondary application)
Carbide type area ISO: P | M | K | S
Carbide type ISO: P30 | P50 | M20 | M40 | K30 | K40 | S20 | S30
Min./max. Vc in steel: 140-165 m/min
Min./max. f in steel: 0.07-0.18 mm/U
Min./max. Vc in stainless steel: 80-95 m/min
Min./max. f in stainless steel: 0.08-0.16 mm/U
Min./max. Vc in cast iron: 130-155 m/min
Min./max. f in cast iron: 0.07-0.18 mm/U
Min./max. Vc in special alloys: 25-45 m/min
Min./max. f in special alloys: 0.08-0.13 mm/U
Number of pieces per packet: 10 PCS

Manufacturer part no.: 6920807

EAN no.: 3603603074293

Product Datasheet
