ATORN SC TiAlNplus high-feed drill, 3xD diameter 3.1 mm, HA shaft, with IC

ATORN SC TiAlNplus high-feed drill, 3xD diameter 3.1 mm, HA shaft, with IC

ATORN SC TiAlNplus high-feed drill, 3xD diameter 3.1 mm, HA shaft, with IC
Item no: 1011140 102

Online price:

Available in 5-7 working days.
Replacement article

Application
Designed for use with very high feeds on stable and high-performance machines

Execution
  • 3-edge drill
  • 4 grinding surfaces with concave main cutting edge
  • 3 drill heels
  • 30° spiral angle

Advantage
  • Up to 50% higher productivity than double-edged drills
  • Perfectly round holes combined with excellent self-centring behaviour, even on uneven surfaces
  • Extremely high feed rates thanks to the special cutting geometry
  • Polished chip spaces and optimised tapered core rejuvenation ensure perfect chip removal
  • Minimum burr formation at hole exit thanks to the 135° tip angle


Brand: ATORN
Material to be processed: Steel | Cast metal
Cutting edge diameter: 3,1 mm
Tolerance of cutting edge diameter: h7
Cutting material: SC
Surface: TiAlN plus
Max. drilling depth (D): 3xD
Type: HPC UNI
Coolant supply: Internal
Tool holding device: HA parallel shank
Angle of the tip: 135 Degree
Shank diameter: 6 mm
Chip flute length: 20 mm
Length: 62 mm
f steel 1000: 0,28 mm/r
DIN: 6537

ATORN-No.: 10915816

EAN no.: 4050293669862

Product Datasheet Datasheet cutting values
Additional articles

Please select a button.

Replacement article
Versions
loading
Keywords:

[Text nicht gefunden]

  • ATORN SC TiAlNplus high-feed drill, 3xD diameter 3.5 mm, HA shaft, with IC
    --
  • ATORN SC TiAlNplus high-feed drill, 3xD diameter 3.9 mm, HA shaft, with IC
    --
  • ATORN SC TiAlNplus high-feed drill, 3xD diameter 10.6 mm, HA shaft, with IC
  •
    ATORN SC TiAlNplus high-feed drill, 5xD diameter 5.0 mm, HA shaft, with IC
  •
    ATORN SC TiAlNplus high-feed drill, 5xD diameter 5.1 mm, HA shaft, with IC
    93,23 €
  • ATORN SC TiAlNplus high-feed drill, 5xD diameter 5.4 mm, HA shaft, with IC
  •
    ATORN SC TiAlNplus high-feed drill, 5xD diameter 5.5 mm, HA shaft, with IC
    93,23 €
  • ATORN SC TiAlNplus high-feed drill, 5xD diameter 5.8 mm, HA shaft, with IC
  •
    ATORN SC TiAlNplus high-feed drill, 5xD diameter 5.9 mm, HA shaft, with IC
  •
    Through hole screw tap for machining alu. 3xD HSS-E/PM CrN DIN376 shape B M16
    70,61 €
  • Through hole screw tap M DIN 371 shape B 3xD HSS-E large chip space for alu. M3
    11,63 €
  • Jigsaw blade set 16 pieces Heavy for Wood and Metal Demolition
